Wood shredder is specially designed to crush wood and reduce the size of materials by shearing, tearing and extruding. It is mainly applied to crushing and recycling of various wood materials such as wood, furniture factory trimmings, waste furniture, wooden pallets, construction templates, logs, branches, stumps, roots, etc.
- Application Materials: wood, roots, stumps, round wood, poles, waste wood furniture, waste wood, wood trimmings, wood pallets, solid wood, branches and other wood products.
- Power: 15kw-160kw | Capacity: 5-60t/h
Guoyu wood shredder is mainly composed of frame, shell, liner, rotating shaft, blade, knife plate, pulley, etc. It covers an area of small, reasonable and compact structure layout, low energy consumption, high efficiency, good molding of finished materials, and is the more ideal choice among wood crushing and processing equipment!
| MODEL | GY-2600 | GY-1900 | GY-1500 | GY-1200 | GY-1000 | GY-600 |
| Spindle Power(kw) | 4-160*2 | 4-90*2 | 4-45*2 | 4-37*2 | 4-30*2 | 4-15*2 |
| Spindle Speed(r/min) | 16-18 | 14-16 | 14-16 | 18-20 | 18-20 | 18-20 |
| Capacity | 25-60 | 10-25 | 8-18 | 6-15 | 5-10 | 2-5 |
| Conveyor Power(kw) | 3-4 | 3-4 | 3-4 | / | / | / |
| Blade Core No.(PCS) | 40 | 40 | 30 | 28 | 30 | 26 |
| Blade Core Dia(mm) | Φ720 | Φ560 | Φ530 | Φ372 | Φ360 | Φ260 |
| Broken Particle Size(cm) | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 |
| Silo Size(m) | 2.5*1.4 | 2.3*2 | 2*2 | 1.4*1 | 1.2*1 | 0.82*0.9 |
| L*W*H(m) | 8.2*4*4.3 | 8*2.5*2.4 | 4*1.7*2.4 | 3.2*2*1.9 | 3*2*1.9 | 2.6*2*1.9 |
| Weight(t) | 36 | 15 | 12 | 6 | 5 | 2.5 |
Related Machine For Sale
Features of Wood Shredder for Sale
- This series of twin shaft shredder has low speed, high torque, low noise, etc. It adopts PLC control system, which can be automatically controlled, with start, stop, reverse and overload automatic reversing control function.
- Motor + reducer drive the knife shaft to achieve low speed and high torque shearing effect.
- The bearings are sealed six times, effectively waterproof and dustproof, prolonging the service life of the bearings.
- The tool wears out and adopts the tool coating and welding repair technology to achieve multiple reuse of the tool and greatly reduce the maintenance cost of the tool.
- Separate lifting type case design, the whole tool shaft (shaft, blade, bearing, sealing system) can be removed easily and quickly.
- The tools are arranged in a spiral line for efficient cutting.
- The tool bore and spindle face are hexagonally designed to achieve uniformity of force on the tool.
- According to the different materials and product shapes to be shredded, different types of knives can be selected.
Wood Shredder Correct Operation and Maintenance
Users in the use of wood shredder equipment should pay attention to the correct use of the way to avoid bringing obstacles to production, effective attention to the following can effectively protect the service life of the machine.
- the use of equipment, to avoid non-wood materials into the machine, such as some nails, metal objects, etc., the machine is used to polish the sharp blades, blades shredding wood materials no problem, if you enter the nails, for the equipment of the blade damage strength is great, and even the phenomenon of card machine.
- processing of wood, the humidity of wood is no requirement, but the humidity of wood is not easy to too large, if the water content is too large more than 20%, the structure of the brittle degree of decline, the feed is not easy to shred, productivity and kWh production are to be reduced.
- equipment maintenance, for the completion of the work hours to calculate the amount, that is, the machine every completed a certain cumulative work as a child, the need for technical maintenance of the machine components. The use of the machine, for the different use of the situation and processing materials to determine the motor running load changes differently, the equipment is subjected to different degrees of heavy maintenance.
